KGH-2B
NTM KGH-2B is a split body with two separate tailgates mainly designed for 3-axle chassis with a gross weight of up to 26 tonnes.
Our two-chamber refuse collection vehicles are designed for efficiency, safety, and versatility, offering industry-leading solutions for waste collection. Equipped with advanced container lifts compliant with SS-EN 1501-5 standards, these vehicles effectively handle containers meeting 840-1, -2, and -3 standards. The lifts come pre-prepared for known weighing systems, ensuring seamless integration and enhancing operational efficiency. Mounted on “blind cells,” the design allows easy retrofitting of chassis scales if needed, while a short rear overhang boosts manoeuvrability, making it a popular choice among drivers.
Safety is a top priority, with a 360° reversing camera providing complete visibility around the vehicle, ensuring safer reversing in all environments. Extra work lighting is also included for enhanced visibility during low-light conditions, and customizable drawers are available to meet specific customer needs. Pre-installed weighing systems, including container lift scales and frame scales, streamline waste management operations and add precision to collection tasks.
Performance and versatility are central to these vehicles. They feature completely separate compression systems with options for either 70/30 or 50/50 distribution, offering the flexibility to handle various waste types. The ability to empty 4-wheel containers from both sides, combined with fast work cycles and strong compression, ensures efficient and reliable operation. Ease of use is paramount, with intuitive controls that make the vehicle straightforward to operate, even in demanding environments.
Designed with durability in mind, the vehicles are available in three different height sizes to meet a range of operational requirements. With robust construction and diverse model variations, our two-chamber refuse collection vehicles deliver the adaptability and performance needed to keep waste management operations running smoothly and efficiently.
Also available with a front pod (see FK system) creating a multi-functional, three-compartment vehicle.
Technical Specifications
- 1. Payload | 3.5 - 12.0 tonne
- 2. Chassis Weight | 18.0 - 32.0 tonne
- 3. System Pressure | 260 bar
- 4. Compression Force | 260 kN
- 5. Hopper Volume | 1.3 m³ + 0.65 m³
- 6. Length | 5.2 - 8.2 m
- 7. Weight (inc barlift) | 7.7 - 9.7 tonne
- 8. Body Volume | 10.0 - 25.0 m³
